All geometry for the model, including geometry from an import or a link, should reside within the limits of the modeling work plane.”
“When you create a Revit model, you are working on a modeling work plane that is 20 miles or 32 kilometers in diameter, with a radius of 10 miles or 16 kilometers from the internal origin. Revit, however, doesn’t come loaded with CS and has further limitations on what the size of your model can be, and the distance from the project origin. A CS must be set in order to use this functionality. Bing Maps is great to serve as a reference tool and has imagery that can easily be turned on and off. Once a coordinate system is selected, you can do things such as turn on Bing Maps, reproject GIS data and images, and many other project related tasks. If you know your CS code, you can simply type it into the box. Setting the coordinate system in Civil 3D is very easy, simply right click on your drawing name from the Settings tab of your Toolspace.įrom the Units and Zone tab you can set your Category (State/Country) and well as choose from a list of available coordinate systems (CS). I thought I’d briefly explain how the coordinates of both Civil 3D and Revit work.Ĭivil 3D is preloaded with a huge library of coordinate systems and easy to create custom coordinate systems, or project coordinate systems in. I am 100% guilty when it comes to both of those statements! But there are some helpful ways to implement Revit to Civil 3D and/or Civil 3D to Revit workflows. And as an architect, sometimes working with the civil engineer’s JUNK is not worth the hassle. The camera is selected in all views where the camera is visible, such as plan, elevation, and other 3D views.Back June 12th, 2021 Implementing Revit Within Your Civil 3D WorkflowĪs a civil engineer, sometimes working with an architect has been nothing more than “Just send me your stuff and I’ll get it in the right spot”. In the Project Browser, right-click the perspective 3D view name, and select Show Camera.Ģ.
To modify the camera position in other views,ġ. Go to the perspective view's element properties and change the eye elevation / taget elevations to change the view's angle. To rename the view, in the Project Browser right-click it, and select Rename.ĥ. Revit Architecture creates a perspective 3D view and assigns a name to the view: 3D View1, 3D View2, and so on. Drag the cursor to the desired target and click. Click in the drawing area to place the camera.Ĥ. Note: If you clear the Perspective option on the Options Bar, the view that is created is an orthographic 3D view and not a perspective view.ģ. Click View tab -> Create panel -> 3D View drop-down -> Camera. Open a plan, section, or elevation view.Ģ.
